Atlas Copco Diamec U6 APC Details

Call Us: +30 210 8213311

Atlas Copco Diamec U6 APC Specs

  • DEMAC Y2-280M-4 / 90kW (122hp)
  • RPM : 1480
  • Electrical motor : PU6E
  • Cooling : water type oil cooler
  • Max pull force : 85kN
  • Feed length : 1400mm
  • Rotation speed : 1400r/min
  • Mud pump : Trido 140H (140lt/min, 70bar)
  • Drilling Capacity : 900m (ΝQ)
  • Wireline hoist : 1300m
  • Max drum pull : 10kN
  • Drilling angle : 90o to -90o

Rig Description

Powerful core drilling rig for underground operations with wireline (A-H) and conventional core barrels. Improved performance and reliability with new drilling design and hydraulic control system.

  • Wireline
  • Skid
  • PQ, HQ, NQ
