Epiroc Christensen C140 Rig Details

Call Us: +30 210 8213311

Epiroc Christensen C140 Specs

  • Cummins QSB 6.7lt Tier 4F 160kW (215hp)
  • RPM : 1800
  • Diesel turbocharged
  • Cooling : water
  • Rod holding force : 130kN
  • Chuck holding capacity : 178kN
  • Mast pull force : 138kN
  • Mast thrust force : 59.6kN
  • Mud pump : Trido 140H (140lt/min, 64bar)
  • Max Torque (Rotation Unit): 7600Nm
  • Max Speed (Rotation Unit): 1300rpm
  • Drilling Capacity : 1400m (ΝQ)
  • Wireline hoist : 2000m
  • Max drum pull : 13kN
  • Drilling angle : 45o-90o

Rig Description

The Christensen surface core drilling rigs have a well-earned reputation for reliability when it comes safety and performance. Large core samples, a gear driven rotation unit and a constant penetration rate allow the Christensen 140 to boost your productivity and profits. The durable Christensen 140 rig is also designed to help you meet tough environmental protection demands anywhere in the world.

  • Wireline
  • Crawler
  • PQ, HQ, NQ
